Sharman AR-600XL Multicom VHF/UHF Antenna Rotor with Controller and Remote Control

The Sharman AR-600XL Multicom is a compact antenna rotor designed for use with small VHF/UHF antennas, TV antennas and light-duty installations where convenient and accurate antenna direction control is required.

This rotor is suitable for radio amateurs using small directional antennas on the 2 metre and 70 centimetre bands, allowing the antenna direction to be changed quickly using either the control unit or the supplied remote control.

The control unit features a digital direction indicator and can store up to 12 antenna positions, making it easy to return quickly to frequently used directions. This is especially useful for repeated contacts in specific areas, repeaters, light-duty satellite use, VHF/UHF reception or operation with small beam antennas.

The set includes the rotor, controller, remote control, mounting clamps, power cable and user manual. The rotor has a robust construction, with a weather-resistant one-piece cast aluminium housing, precision metal gears and steel thrust bearings for improved durability.

The AR-600XL operates from 220–230VAC and requires a 3-wire control cable, not included. It is a practical solution for light VHF/UHF installations, provided the antenna used is within the recommended mechanical limits.

Main features

VHF/UHF antenna rotor
Manufacturer / brand: Sharman
Model: AR-600XL Multicom
Reference: AR600XL
EAN: 5056109260086
Equipment type: antenna rotor with controller
Main application: rotation of small VHF/UHF antennas
Programmable directions: up to 12 positions
Controller: included
Direction indicator: digital
Remote control: included
Remote control type: universal remote for 3 devices
Compatible mast size: 28 to 44mm
Rotation time: approximately 74 seconds
Rotation torque: 21.5Nm
Approximate weight: 4.2kg
Power supply: 220–230VAC
Required control cable: 3-wire cable
Control cable included: no
Rotor construction: weather-resistant cast aluminium housing
Gears: precision metal gears
Bearings: steel thrust bearings
Mounting clamps: included
Power cable: included
User manual: included
Suitable for small VHF/UHF antennas, TV antennas and light-duty installations

Package contents

Sharman AR-600XL rotor
Controller / control unit
Universal remote control for 3 devices
Mounting clamps
Power cable
User manual

Recommended applications

Small VHF/UHF antennas
Compact 2m beams
Compact 70cm beams
Directional TV antennas
Light-duty amateur radio installations
VHF/UHF reception
Base stations with small directional antennas
Low-load rotating antenna projects
Use with digital direction controller
Installations where several antenna directions need to be stored

Important note

Before installation, always confirm the mast diameter, antenna weight, wind load, mechanical load, antenna type, installation height, mounting method, control cable and local weather conditions.

The Sharman AR-600XL is intended for small antennas and light-duty installations. It is not suitable for larger 6m antennas, large VHF beams or HF Yagi antennas. For larger antennas or installations exposed to higher wind load, a higher-capacity rotor should be selected.

The 3-wire control cable is not included and should be selected with a suitable conductor size for the installation. The power supply is 220–230VAC, so installation should be carried out carefully, following electrical safety rules and ensuring proper protection against moisture and weather exposure.
