1 nF 100 V ±10% Polyester Film Capacitor – 5 mm Lead Spacing

This polyester film capacitor has a nominal capacitance of 1 nF, equivalent to 1000 pF or 0.001 µF, and supports an operating voltage of up to 100 V.

Its non-polarized construction allows installation in either electrical orientation, making it suitable for signal circuits, filtering, coupling, timing and electrical noise suppression.

The radial leads with 5 mm spacing make it easy to install on printed circuit boards, prototypes and electronic equipment. Its ±10% tolerance and wide operating temperature range make it suitable for various electronic applications.

Main features

• Type: polyester film capacitor
• Capacitance: 1 nF
• Equivalent capacitance: 1000 pF / 0.001 µF
• Capacitance code: 102
• Rated voltage: 100 V
• Tolerance: ±10%
• Tolerance code: K
• Polarity: non-polarized
• Lead spacing: 5 mm
• Lead arrangement: radial
• Mounting type: through-hole
• Approximate dimensions: 2.5 × 6.5 × 7.2 mm
• Operating temperature: -55 to +105 °C
• Climatic category: 55/100/56
• Climatic category standard: IEC 60068-1

Recommended applications

• Signal filtering
• Coupling and decoupling
• Electrical noise suppression
• Timing circuits
• Audio equipment
• Radio and telecommunications circuits
• Electronic equipment repair
• Printed circuit boards and prototypes

Important note

This capacitor is non-polarized, so it does not have positive and negative terminals.

The applied voltage must not exceed the specified 100 V rating. This component does not have an X or Y safety classification and must not be connected directly across AC mains conductors or between the mains and earth without the appropriate safety certification.
