5pF 500V ±0,5pF Radial Mica Capacitor

The CD15CD050DO3F is a standard dipped mica capacitor from the CD15 series, designed for electronic applications requiring low capacitance, stable performance and tight tolerance.

With a capacitance value of 5pF, rated voltage of 500V and ±0.5pF tolerance, this component is suitable for radio frequency circuits, oscillators, filters, resonant circuits, timing applications, radio equipment repair and electronic projects where capacitance stability is important.

Mica capacitor technology is commonly used in applications that require good thermal stability, low losses and reliable behaviour at higher signal frequencies. The radial package allows easy installation on printed circuit boards, perfboards and during electronic repairs.

Main features

• Mica capacitor
• Manufacturer / brand: Knowles / Illinois Capacitor
• Family / series: CD15
• Part number: CD15CD050DO3F
• Capacitance: 5pF
• Rated voltage: 500V
• Tolerance: ±0.5pF
• Temperature coefficient: 200 ppm/°C
• Mounting type: radial / THT
• Termination style: radial
• Lead spacing: 5.9mm
• Approximate dimensions: 11.4 x 4.8 x 9.1 mm
• Minimum operating temperature: -55°C
• Maximum operating temperature: +125°C
• Packaging: Bulk
• Non-polarized component
• Suitable for precision and stability-focused applications

Recommended applications

• RF circuits
• Oscillators
• Radio frequency filters
• Resonant circuits
• Low-capacitance coupling and decoupling
• Timing circuits
• Radio and electronic equipment repair
• Communication equipment
• Instrumentation
• Electronic projects requiring a stable 5pF capacitor

Important note

Before use, always check capacitance value, rated voltage, tolerance, lead spacing and physical dimensions. Although this is a high-stability mica capacitor, the final choice must match the real circuit conditions, including voltage, frequency, temperature and available PCB space.
