7 pF 500 V ±0,5 pF Radial Mica Capacitor

The CD15CD070DO3F is a standard dipped mica capacitor from the CD15 series, suitable for electronic applications where low, stable capacitance and tight tolerance are required.

With a value of 7pF, 500V rated voltage and ±0.5pF tolerance, this component is suitable for radio frequency circuits, oscillators, filters, resonant circuits, timing, radio equipment repair and electronic projects where capacitance stability is important.

Mica capacitor technology is widely used in applications requiring good thermal stability, low losses and reliable behaviour with high-frequency signals. The radial package makes it easy to mount on printed circuit boards, prototyping boards and during electronic equipment repairs.

Main features

Mica capacitor
Manufacturer / brand: Knowles / Illinois Capacitor
Family / series: CD15
Part number: CD15CD070DO3F
Capacitance: 7pF
Rated voltage: 500V
Tolerance: ±0.5pF
Temperature coefficient: 200 ppm/°C
Mounting: radial / THT
Termination style: radial
Lead spacing: 5.9mm
Approximate dimensions: 11.4 x 4.3 x 9.1 mm
Minimum operating temperature: -55°C
Maximum operating temperature: +125°C
Packaging: Bulk
Non-polarized component
Suitable for precision and stability applications

Recommended applications

RF circuits
Oscillators
Radio frequency filters
Resonant circuits
Low-capacitance coupling and decoupling
Timing circuits
Radio and electronic equipment repair
Communication equipment
Instrumentation
Electronic projects requiring a stable 7pF capacitor

Important note

Before use, always confirm the capacitance value, rated voltage, tolerance, lead spacing and physical dimensions. Although this is a high-stability mica capacitor, the final selection must match the real circuit conditions, including voltage, frequency, temperature and available board space.
