The Goobay Ultra-Slim RJ45 LAN Window Feed-Through, part number 71412, allows a network connection to pass through a window or door without drilling holes in the wall or frame.

Its central section is made from transparent, flexible PCB foil measuring only 0.3 mm thick, allowing the window to be closed carefully over the adapter.

Both ends feature RJ45 female 8P8C sockets with nickel-plated contacts and bend protection. A conventional network patch cable is required on each side of the adapter to complete the connection.

At 30 cm long, this version provides additional reach for wider window frames or for positioning the RJ45 sockets more conveniently.

The package includes two adhesive pads and four screws, allowing the adapter to be secured near the frame and reducing mechanical stress on the flexible PCB section.

Main features

• Brand: Goobay
• Part number: 71412
• EAN: 4040849714122
• Type: Ethernet window feed-through
• Length: 0.30 m
• Flexible-section thickness: approximately 0.3 mm
• Connectors: 2 × RJ45 female (8P8C)
• Contact material: nickel-plated
• Flat-section material: transparent PCB foil
• Shielding: unshielded
• Bend protection: both ends
• Stated maximum transmission rate: approximately 10 Mbit/s
• Cable covering: weather-resistant
• Colour: transparent with visible tracks
• Approximate weight: 25 g
• Markings: CE and WEEE
• Package contents: window feed-through, 2 adhesive pads and 4 screws

Recommended applications

• Routing network connections through windows
• Routing Ethernet connections through doors
• Connecting equipment installed outdoors
• IP cameras with wired network connections
• Access points and antennas with Ethernet interfaces
• Temporary installations without drilling
• Rented properties where walls cannot be modified
• Low-speed network connections

Important note

The manufacturer states a maximum transmission rate of only approximately 10 Mbit/s. This product is unsuitable when the full performance of Fast Ethernet, Gigabit Ethernet or faster networks is required.

The manufacturer does not confirm PoE compatibility. As a precaution, do not use it to power equipment through PoE without prior technical confirmation.

This product does not replace a complete network cable: one conventional RJ45 patch cable must be connected at each end.

Before permanent installation, close the window slowly and confirm that the frame does not cut, puncture or place excessive pressure on the foil. Avoid sharp folds and protect the RJ45 sockets from direct water ingress.
